Xerox Phaser 6120

P1 Duplex Unit
Phaser® 6120 Color Laser Printer Service Manual
9-30
P1 Duplex Unit
P1 Duplex Unit Parts List Table
Key Part No. Description Qty Comments
1 TOP COVER 1
2 011E20130 LEVER 2
3 PRESSURE SPRING 2
4 GEAR 33/50T 1
5 GEAR 12/47T 1
6 127E15300 DUPLEX MOTOR 2 M8/M9 DU
7 GEAR 16/27T 1
8 GEAR 16T 1
9 COLLAR 1
P 1
M8 DU
M9 DU
PC11 DU
PC12 DU
PC10 DU
PWB-A DU
b
c
c
c
b
b
b
b
d
d
a
b
a
1
24
4
7
8
5
9
11
21
22
16
10
17
23
15
20
14
14
6
10
19
18
17
10
16
13
6
12
2
2
3
3
