Xerox Phaser 6120 Service Manual

P1 Duplex Unit
Phaser® 6120 Color Laser Printer Service Manual
9-31
10 130E11800 DUPLEX SENSOR (PC10, 11,
12)
3
PC10=Paper Loop Sensor
PC11=Door Sensor
PC12= Transport Sensor
11 BRACKET ASSY 1
12 BRACKET 1
13 RIGHT COVER 1
14 SHOULDER SCREW 2
15 PLATE SPRING 1
16 TORSION SPRING 2
17 120E29310 ACTUATOR 2 Paper Loop Sensor
18 SHIELD 1
19 960K25590 PWB-A DU (Duplex Board) 1
20 REGULATING PLATE 1
21 COVER 1
22 LOWER COVER 1
23 COVER 1
24 FRAME 1
a
b
c
d
604K35500 Part of the Hardware Kit
P1 Duplex Unit Parts List Table (Continued)
Key Part No. Description Qty Comments

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
