Xerox Phaser 6120 Service Manual

Print Engine Theory of Operation
Phaser® 6120 Color Laser Printer Service Manual
7-51
Monochrome Ordinary/Low Environment
The low temperature environment refers to the condition, in which the Temperature/Humidity
Sensor (HS1) detects a temperature of less than 20° C.
Color Environment
Length
210 mm
(8.2”)
211 - 216 mm
(8.3” - 8.5”)
217 - 257 mm
(8.6” - 10.1”)
258 - 297 mm
(10.2” - 11.7”)
Width 92 - 138 mm
(3.6” - 5.4”)
14/12 14/12 14/12 14/12
139 - 147 mm
(5.5” - 5.8”)
18/15 18/15 14/12 14/12
148 - 181 mm
(5.9” - 7.1”)
19/16 18/15 14/12 14/12
182 - 209 mm
(7.2” - 8.2”)
20/17 20/17 20/17 14/12
210 - 216 mm
(8.3” - 8.5”)
20/20 20/20 20/20 20/20
Length
210 mm
(8.2”)
211 - 216 mm
(8.3” - 8.5”)
217 - 257 mm
(8.6” - 10.1”)
258 - 297 mm
(10.2” - 11.7”)
Width 92 - 138 mm
(3.6” - 5.4”)
33 3 3
139 - 147 mm
(5.5” - 5.8”)
55 3 3
148 - 181 mm
(5.9” - 7.1”)
55 3 3
182 - 209 mm
(7.2” - 8.2”)
55 5 3
210 - 216 mm
(8.3” - 8.5”)
55 5 5

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
