Xerox Phaser 6120

Print Engine Parts List
Phaser® 6120 Color Laser Printer Service Manual
6-4
Diagrams of Main Parts
No. Description Parts List No. Page No.
1 External Parts P1 page 6-6
2 Top Cover P2
P3
page 6-8
page 6-10
3 Main Frame P4 page 6-12
4 Left Frame P5 page 6-14
5 Right Frame P6
P7
page 6-16
page 6-18
6 Drive Section P8
P9
P10
P11
page 6-20
page 6-22
page 6-24
page 6-26
7 Laser (PH) Section P12 page 6-28
REAR SIDE
10
9
7 13
12
1
65
3
82 11
4
