Xerox Phaser 6120

Print Engine Parts List
Phaser® 6120 Color Laser Printer Service Manual
6-5
8 Transfer Section P13 page 6-30
9 Transfer Roller Section P14 page 6-32
10 Vertical Transport Section P15 page 6-34
11 Fuser P16 page 6-36
12 Electrical Components P17 page 6-38
13 Paper Take-Up Section P18
P19
P20
page 6-40
page 6-41
page 6-43
Wiring P21
P22
P23
page 6-45
page 6-46
page 6-47
Wiring Accessories and Jigs P24 page 6-48
Accessory Parts P25 page 6-49
No. Description Parts List No. Page No.
