Xerox Phaser 6120 Service Manual

Service Parts Disassembly
Phaser® 6120 Color Laser Printer Service Manual
8-4
Service Parts Disassembly
Variable Resistors on Board
Do not turn the variable resistors on boards for which no adjusting instructions are given in
Adjustment/Setting.
Removal of PWBs
■ When removing a circuit board or other electrical component, refer to “Handling of
PWBs” and follow the corresponding removal procedures.
■ The removal procedures given in the following omit the removal of connectors and
screws securing the circuit board support or circuit board.
■ Where it is absolutely necessary to touch the ICs and other electrical components on
the board, be sure to ground yourself.
Disassembly Index
No Section Part name Ref. page
1 Lower Feeder Unit page 8-5
2 Exterior parts Tray page 8-5
3 Lower Feeder Unit Rear Cover page 8-5
4 Unit Lower Feeder Paper Pick-up Unit page 8-6
5 Board and etc Lower Feeder Board page 8-7
6 Others Lower Feeder Paper Pick-up Solenoid page 8-8
7 Lower Feeder Paper Size Switch page 8-9

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
