Menu Map
Phaser® 6120 Color Laser Printer Service Manual
3-11
Menu Map
Printing the Menu Map
The Menu Map helps you navigate the control panel menus. To print the Menu Map:
1. On the control panel, select Printable Pages Menu, and then press the Menu/Select key.
2. Select Menu Map, and then press the Menu/Select key.
3. Select Yes , and then press the Menu/Select key.
List of Menu Functions
*1 This setting is
available only when
an optional Hard
Drive is installed.
*2 This setting is
available only when
an optional Lower
Feeder Unit is
installed.
*3 This setting is
available only when a
Duplex Unit is
installed.
PROOF/PRINT MENU *1
MENU
PAPER MENU
QUALITY MENU
PRINTABLE
PAGES MENU
POSTSCRIPT
PCL
INPUT TRAY
DUPLEX *3
ORIENTATION
JAM RECOVERY
BLACK
CYAN
MAGENTA
YELLOW
TRAY 1 MODE
TRAY 1
TRAY 2
AUTO CONTINUE
TRAY SWITCHING
CUSTOM
MAP
MENU MAP
CONFIGURATION
SUPPLIES PAGE
FONT LIST
DIRECTORY LIST
DEMO PAGE
TONER REMOVAL
TONER OUT ACTION
DENSITY CAL
DENSITY CONTROL
TRANSFER BELT
BLACK
CYAN
MAGENTA
YELLOW
REMOVE ALL
REQUEST CAL

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
