Xerox Phaser 6120 Service Manual

Index of Control Panel Messages
Phaser® 6120 Color Laser Printer Service Manual
3-10
For details of malfunction messages and troubleshooting procedures, see Print Engine
Troubleshooting on page 4-1
ERROR 10 - LASER UNIT P/H unit error
ERROR 12 - LASER UNIT Laser unit error
ERROR 14 - TRANSFER ROLLER Transfer roller error
ERROR 15 - TRANSFER BELT Transfer belt error
ERROR 16 - TRANSFER BELT Transfer belt error
ERROR 17 - TONER CAROUSEL Toner rack error
ERROR 18 - FUSER WARMUP Fuser temp error
ERROR 19 - FUSER LOW TEMP Fuser temp error
ERROR 1A - FUSER Fuser temp error
ERROR 1B - FUSER Fuser temp error
ERROR 21 - OHP DETECT SENSOR OHP (PC2A) sensor error
ERROR 23 - WASTE TONER Waste toner detection sensor (PWB-C) error
ERROR 24 - FUSER TEMP Fuser temp error
ERROR 29 - NVRAM COUNTER NVRAM counter error
ERROR 2A - NVRAM COUNTER NVRAM data error
ERROR 2B - NVRAM ACCESS NVRAM access error
Error 2C - NVRAM INSTALL NVRAM installation error
FIRMWARE UPDATE WRITING ERROR FLASH error
Fatal Error Messages (Continued)
Message Description

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
