Xerox Phaser 6120 Service Manual

Index of Control Panel Messages
Phaser® 6120 Color Laser Printer Service Manual
3-9
MAGENTA TONER
MISSING
Magenta toner cartridge is not installed.
When more than one cartridge is missing, the Control Panel messages "xx
TONER/MISSING" for the corresponding missing cartridges is shown with
the priority in the order of c/b/y/m. The developing rack will be positioned so
that the user can install the corresponding missing cartridge in the order of c/
b/y/m.
The message may also appear if the engines does not recognize the
cartridge as a Xerox product.
BLACK TONER
MISSING
Black toner cartridge is not installed.
When more than one cartridge is missing, the Control Panel messages "xx
TONER/MISSING" for the corresponding missing cartridges is shown with
the priority in the order of c/b/y/m. The developing rack will be positioned so
that the user can install the corresponding missing cartridge in the order of c/
b/y/m.
The message may also appear if the engines does not recognize the
cartridge as a Xerox product.
YELLOW TONER
MISSING
Yellow toner cartridge is not installed.
When more than one cartridge is missing, the Control Panel messages "xx
TONER/MISSING" for the corresponding missing cartridges is shown with
the priority in the order of c/b/y/m. The developing rack will be positioned so
that the user can install the corresponding missing cartridge in the order of c/
b/y/m.
The message may also appear if the engines does not recognize the
cartridge as a Xerox product.
PRINTER COVER OPEN Printer Front cover is open.
DUPLEX UNIT
DOOR OPEN
Duplex cover is open.
DISK ERROR Disk Error: full or broken condition.
DISK FULL Disk Error: full or broken condition. Format hard drive or replace. Cancel key
Is active to release temporarily.
ERROR LOADING
Generic message to be used when the situation does not match and specific
errors. The user should attempt the download process again.
FIRMWARE UPDATE
FORMAT ERROR
Error occurred while formatting. The user should attempt the download
process again.
FIRMWARE UPDATE
INVALID IMAGE
The download image could not be decompressed (bad data) or was a wrong
version, header length, etc. The user should attempt the download process
again.
Fatal Error Messages
Message Description
ERROR 04 - ENGINE BOARD Engine board error
ERROR 05 - FLASH ROM Retry engine firmware rewriting process error
ERROR 08 - MAIN MOTOR Main motor (M1) error
ERROR 0B - TRANSFER FAN Transfer fan error
ERROR 0C - PWR SUPPLY FAN Power supply fan error
ERROR 0F - DUPLEX FAN Duplex fan error
ERROR 10 - LASER UNIT P/H unit error
Error Messages (Continued)
Message Description

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
