Xerox Phaser 6120 Service Manual

Index of Control Panel Messages
Phaser® 6120 Color Laser Printer Service Manual
3-8
PAPER JAM TRAY 1 Jam at Tray 1
Or
Paper exists at Tray 1 after jam occurs.
PAPER JAM TRAY 2 Jam at Tray 2
Or
Paper exists at Tray 2 after jam occurs.
PAPER JAM DUPLEX Jam at Switchback
or
Jam at duplex paper path (07H) or
Paper exists at refeed area /switchback section of duplex option after jam
occurs.
PAPER JAM TRANSFER Jam at Transfer Roller
or
Paper exists at Transfer Roller after jam occurs.
PAPER JAM FUSER Jam at Fusing Unit
or
Paper exists at Fuser area after jam occurs.
PAPER JAM EXIT Jam at Ejection section
or
Paper exists at Fuser area after jam occurs.
DENSITY SENSOR
ERROR
PUT [paper size] [paper
type] IN ANY T RAY
PUT [paper size] [ media type]
IN ANY TRAY
By putting specified paper in specified tray and closing tray, printer
automatically restarts.
Cancel Key is Active
PUT [paper size] [paper
type] IN TRAY1
PUT [paper size] [ media type]
IN TRAY1
By putting specified paper in specified tray and closing tray, printer
automatically restarts.
Cancel Key is Active
IMAGING UNIT
MISSING
Drum is not attached.
CYAN TONER MISSING Cyan toner cartridge is not installed.
When more than one cartridge is missing, the Control Panel messages "xx
TONER/MISSING" for the corresponding missing cartridges is shown with
the priority in the order of c/b/y/m. The developing rack will be positioned so
that the user can install the corresponding missing cartridge in the order of c/
b/y/m.
The message may also appear if the engines does not recognize the
cartridge as a Xerox product.
Error Messages (Continued)
Message Description

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
