Xerox Phaser 6120 Service Manual

Phaser® 6120 Color Laser Printer Service Manual
10-2
Use the alpha-numeric grid locators contained in the Overall Wiring Diagram on page 10-3 to
locate the specific section needed, and then go to the corresponding pages for larger versions
of that section.
Control Block Diagram
Wiring Diagram Legend
Print Control Board (PWB-P)
Mechanical Control Board (PWB-A)
Write Unit (PH)
Image processing
CPU
Control Panel (PWB-OP)
Paper Pick-up/ transport
TC/Y TC/M TC/C TC/K
Control System Line
Image Bus Line
Fusing
Duplex Unit* Lower Feeder Unit*
Power supply/ high voltage
4139T2E501DA
Image process
Legend

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
