Xerox Phaser 6120 Service Manual

Misfeed/Jam Troubleshooting Procedures
Phaser® 6120 Color Laser Printer Service Manual
4-8
Actions
Paper Jam Transfer Roller
Timing Detection and Description
Steps Action
WIRING DIAGRAM
Control Signal
Location (Electrical
Component)
1 Initial check items. - -
2 Check the PWB-A connector for
proper connection and correct as
necessary.
--
3 PC1 sensor check. PWB-A PJ12A-3 (ON) 2-C
4 SL1 operation check. HV PJ2HV-2 (REM)
REM = Solenoid On
4-A
5 Change PWB-A. - -
Type Description
There is a misfeed at the 2nd transfer section. The paper does not unblock the Registration Sensor
(PC1) even after the lapse of a predetermined period of
time after the Registration Roller Solenoid (SL2) has
been de-energized.
The Fusing Paper Loop Sensor (PC8) is not blocked by
the paper that has moved past the position, at which the
sensor is blocked.
Detection of paper left in 2nd transfer
section
The Registration Sensor (PC1) is blocked when the
Power Switch is turned ON, a cover is opened and
closed, or a misfeed or malfunction is reset.
The Fusing Paper Loop Sensor (PC8) is blocked when
the Power Switch is turned ON, a cover is opened and
closed, or a misfeed or malfunction is reset.
Relevant Electrical Parts
Registration Sensor (PC1)
Fusing Paper Loop Sensor (PC8)
Registration Roller Solenoid (SL2)
PWB-A (Engine Control Board)

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
