Xerox Phaser 6120 Service Manual

Description of the Control Panel
Phaser® 6120 Color Laser Printer Service Manual
3-5
Caution Display
A caution display appears when an event occurs that requires user intervention, but does not
affect printing.
Error Display
This display appears when an error occurs that can be taken care of by the user.
Malfunction Screen
This screen appears when a malfunction occurs that requires a service technician.
4139F3E502DA
IMAGING UNIT
4139F3E502DA
IMAGING UNIT LOW
4139F3E503DA
REPLACE IMAGING
UNIT
4139F3E504DA
ERROR 08 - MOTOR

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
