Phaser® 6120 Color Laser Printer Service Manual
3-14
PRINTABLE PAGES MENU
MENU MAP
CONFIGURATION
SUPPLIES PAGE
FONT LIST
POSTSCRIPT
PCL
DIRECTORY LIST
DEMO PAGE
Function Prints the Menu Map.
Use To check the available menu settings.
Setting/procedure Select MENU MAP and press the Menu Select key.
Function Prints the Configuration Page.
Use To check configuration of the machine. The following items can be checked:
Printer Information
Printer Interfaces
INSTALLED OPTIONS
PAPER SETTINGS
Setting/procedure Select CONFIGURATION and press the Menu Select key.
Function Prints the Supplies Page.
Use To check the consumable status and the usage of the machine, such as the
number of pages printed.
Setting/procedure Select SUPPLIES PAGE and press the Menu Select key.
Function Prints a list of PostScript fonts.
Use To check the available PostScript fonts.
Setting/procedure Select FONT LIST→ POSTSCRIPT and press the Menu Select key.
Function Prints a PCL fonts.
Use To check the available PCL fonts.
Setting/procedure Select FONT LIST→ PCL and press the Menu Select key.
Function Prints a directory list of the hard drive and flash.
Use To check the files saved on the hard drive and in flash.
Setting/procedure Select DIRECTORY LIST and press the Menu Select key.
Note: This menu item appears only if the optional hard drive is installed.
Function Prints the Demo Page.
Use To print a Demo Page.
Setting/procedure Select DEMO and press the Menu Select key.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
