Xerox Phaser 6120

Print Engine Theory of Operation
Phaser® 6120 Color Laser Printer Service Manual
7-8
Imaging Unit (DC)
Imaging Unit Drive
4139to1570c1 4139to2056e0
Drum Cartridge
Photo Conductor
Charge Generating Layer
Aluminum Base
Charge Transport Layer
4139to2057e0
Main Motor
Photo Conductor
4139to1058e0
