Xerox Phaser 6120

Print Engine Parts List
Phaser® 6120 Color Laser Printer Service Manual
6-48
P24 Wiring Accessories
*Items 1-7 included in the hardware kit.
P24 Wiring Parts List Table
Key Part No. Description Qty Comments
1 WIRING SADDLE 4
2 WIRING SADDLE 5.2H 6
3 WIRING SADDLE 18.5H 3
4 WIRING SADDLE 14.4H 4
5 WIRING SADDLE 8.0H 1
6 CABLE TIE 104L 2
7SO CLIP 1
11 16 21 26
12 17 22 27
13 18 23 28
9 14192429
10 15 20 25 30
7.3
4.8
5.2
11
3.6
16.2
8
8.9
6.2
14.4
11.5
L=104
11.5
28
8
16
2
3
4
5
7
