Xerox Phaser 6120

P3 Duplex Unit
Phaser® 6120 Color Laser Printer Service Manual
9-33
P3 Duplex Unit
P3 Duplex Unit Parts List Table
Key Part No. Description Qty Comments
1 BUSHING 2
2 ROLLER 1
3ROLL 2
4 PLATE SPRING 1
5 GEAR 20T 1
6 GEAR 28T 4
7 GEAR 13/53T 2
8 GEAR 33/50T 1
9 GEAR 23/29T 1
10 DRUM 1
11 RATCHET WHEEL 1
