Xerox Phaser 6120 Service Manual

Print Engine Parts List
Phaser® 6120 Color Laser Printer Service Manual
6-37
14 BRACKET 1
15 BUSHING 1
16 TORSION SPRING 1
17 LEVER 1
18 126K23190 FUSING UNIT 120V 1 Includes all parts shown
within the dotted line.
18 126K23200 FUSING UNIT 230V 1
19 GUIDE 1
20 EXIT SENSOR (PC7) 1
21 120E29290 ACTUATOR 1 EXIT SENSOR
22 PLATE SPRING 2
23 PLATE SPRING 2
24 COLLAR 2
25 ROLLER 1
26 WIRE HARNESS ASSY 1
a, b,
c, d,
e, f, g
604K35500 Part of Hardware Kit
P16 Fusing Unit Parts List Table (Continued)
Key Part No. Description Qty Comments

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
