Xerox Phaser 6120 Service Manual

Print Engine Parts List
Phaser® 6120 Color Laser Printer Service Manual
6-42
13 TENSION SPRING 1
14 FRICTION SHEET 1
15 PLATE SPRING 1
16 GEAR 27T 1
17 CAM 1
18 059E05460 ROLLER 1
19 STOPPER 2
20 SHAFT 1
21 GEAR 27T 1
22 BRACKET 1
23 121E20250 TRAY 1 PAPER PICK
SOLENOID (SL1)
1
24 SHIELD 1
25 DRUM 1
26 RATCHET 1
27 TORSION SPRING 1
28 GEAR 35T 1
29 WASHER 1
30 BRACKET 1
31 GEAR 21/25T 1
32 GEAR 14/20T 1
33 GEAR 14T 1
34 LEVER ASSY 1
35 TENSION SPRING 1
36 GEAR 17/26T 1
37 GEAR 20T 1
38 CAM 1
39 PRESSURE SPRING 1
a
b
c
604K35500 Part of Hardware Kit
P19 Paper Take-Up Section 2 Parts List Table (Continued)
Key Part No. Description Qty Comments

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
