Xerox Phaser 6120 Service Manual

P2 Paper Take-Up Section
Phaser® 6120 Color Laser Printer Service Manual
8-20
10 059E05470 PICK ROLLER 2 1 per part number Always
order a quantity of 2 for this
part.
11 SHAFT 1
12 110E19930 SWITCH (DETECT) S4 1
13 BRACKET 1
14 SHAFT 1
15 BUSHING 1
16 121E20310 TRAY 2 PICK-UP SOLENOID
(SL7)
1
17 GEAR 38T 1
18 TENSION SPRING 1
19 COVER 1
20 GEAR 20/26T 1
21 GEAR 22T 1
22 807E17790 GEAR 17T 1
a
b
c
d
e
604K35500 Part of Hardware Kit
P2 Paper Take-Up Section Parts List Table (Continued)
Key Part No. Description Qty Comments

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
