Xerox Phaser 6120 Service Manual

Print Engine General Information
Phaser® 6120 Color Laser Printer Service Manual
1-8
Operating Environment
Printer Recommended
Duty Cycle
Average Number of Printed Sheets (Monthly): 650 pages (A4 and Letter size
5% coverage)
Maximum Number Of Printed Sheets (Monthly): 35K pages (A4 and Letter 5%
coverage)
Printer Life 200,000 pages or 5 years
Printer Serial Number YGG = 120 V printer
YGH = 220 V printer
The first digit of the serial number string is the revision of the printer. The
remaining 5 digits represent the actual serial number of the printer.
Power
Requirements
Voltage:
AC 110 to 127 V
AC 220 to 240 V
Frequency: 50/60 Hz ± 3 Hz
Max Power
Consumption
1100 W (Maximum peak)
Dimensions 442 mm (W) x 395 mm (D) x 341 (H) mm
16.9" (W) x 15.6" (D) x 13.4" (H)
Weight Approximately 19.6 kg (43.9 lb.) (excluding the Dust Cover)
Operating Noise During standby: 35 dB (A) or less
During printing: 54 dB (A) or less
Operating Range
Temperature
10° to 32° C / 50° to 90° F (with a fluctuation of 10° C / 18° F or less per hour)
Operating Range
Humidity
10%-80% RH @ 15° to 32° C/59° to 89° F to with water vapor no higher than
25.5 C/77.9° F 80% condition. Five operating corners are 15° C /59° F/15%, 15° C/
80%, 25.5° C / 77.9° F/80%, 32° C /60%, 32° C / 89° F/15%
Operating Range
Altitude
0-2,500 meters (8,000 ft.)
Transportation
Range
Temperature
-20° C to +55° C/-4° to 131° F
Transportation
Range
Humidity
30%-85% RH, non-condensing
Transportation
Range
Altitude
0-6,092 meters (20,000 ft.)
Storage Range
Temperature
Normal: 0° to 35° C / 32° to 95° F
15%-80% RH For 18 months max
Severe: -20° to 40° C / -4° to 104° F
5%-95% RH For 1 month max
Note: Applies only to CRUs.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
