Xerox Phaser 6120 Service Manual

Menu Map
Phaser® 6120 Color Laser Printer Service Manual
3-16
MEDIA TYPE
CUSTOM
WIDTH
LENGTH
AUTO CONTINUE
TRAY SWITCHING
Function Specifies the setting for the type of media loaded in Tray 2.
Use To specify the type of media loaded in Tray 2.
Setting/procedure The default setting is PLAIN PAPER.
PLAIN PAPER, LETTERHEAD
Function Specifies the width of the custom-sized paper in Tray 1.
Use To specify the width of the custom-sized media in Tray 1.
Setting/procedure
■ On the model for North America, the settings appear in inches and the
menu item appears as WIDTH (IN). On the models for all other regions,
the settings appear in millimeters and the menu item appears as
WIDTH (MM).
■ The default setting is 92.0 mm (3.62 in.).
92.0 to 216.0 mm (3.62 to 8.50 in.)
Function Specifies the length of the custom-sized paper in Tray 1.
Use To specify the length of the custom-sized media in Tray 1.
Setting/procedure
■ On the model for North America, the settings appear in inches and the
menu item appears as LENGTH (IN). On the models for all other regions,
the settings appear in millimeters and the menu item appears as
LENGTH (MM).
■ The default setting is 148.0 mm (5.83 in.).
148.0 to 356.0 mm (5.83 to 14.02 in.)
Function Enables or disables printing when the size of the media loaded in the tray
does not match that of the print data.
Use To print data on the media loaded in the tray of the media loaded in the tray
does not match that of the print data.
Setting/procedure The default setting is ON.
“ON”, OFF
Function Allows a print cycle to continue without interruption when the current tray
runs out of media during the print cycle by automatically reselecting another
tray, in which the media of the same size and the same type is loaded.
Use To allow media to be pulled from another tray when the media in the first tray
runs out.
Setting/procedure The default setting is ON.
“ON”, OFF
Note: This setting is available only when an optional Lower Feeder Unit is
installed.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
