Phaser® 6120 Color Laser Printer Service Manual
3-29
DUPLEX DENSITY
The duplex density function allows the user to adjust the toner density (T/C) to compensate for
an image quality (light or dark duplex print) issue that may occur in duplex outputs, when the
printer operates in certain climates, such as dry or high humidity.
Function Adjusts the toner cartridge (T/C) ratio control level when a faulty image
density occurs due to changes in weather or environment.
Use To adjust the T/C ratio changes to compensate for changes in the user's
operating environment during 2-sided printing.
Setting/procedure The default setting is 0.
1. Call the ENVIRONMENT MENU to the menu screen.
2. With DUPLEX DENSITY selected, press the < or > key as necessary to
select the appropriate density level value.
Adjustment range: -3 to +3
3. Press the Menu/Select key to accept the new density level setting.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
