Xilinx SelectIO 7 Series User Manual

7 Series FPGAs SelectIO Resources User Guide www.xilinx.com 67
UG471 (v1.10) May 8, 2018
Supported I/O Standards and Terminations
Figure 1-50 shows a sample circuit illustrating a termination technique for HSTL class-II
(1.5V or 1.8V) with bidirectional termination. In a specific circuit, all drivers and receivers
must be at the same voltage level (either 1.5V or 1.8V); they are not interchangeable. Only
HP I/O banks support the DCI standards. The internal split-termination resistors are
always present, independent of whether the drivers are 3-stated.
X-Ref Target - Figure 1-50
Figure 1-50: HSTL Class II (1.5V or 1.8V) Bidirectional Termination
Z
0
IOB
IOB
HSTL_II
HSTL_II_18
HSTL_II
HSTL_II_18
HSTL_II_DCI
HSTL_II_DCI_18
HSTL_II_DCI
HSTL_II_DCI_18
ug471_c1_40_121214
R
P
= Z
0
= 50Ω
R
P
= Z
0
= 50Ω
Z
0
IOB
IOB
V
CCO
= 1.5V for HSTL_II_DCI
1.8V for HSTL_II_DCI_18
V
CCO
= 1.5V for HSTL_II_DCI
1.8V for HSTL_II_DCI_18
R
VRN
= 2Z
0
= 100Ω
R
VRP
= 2Z
0
= 100Ω
+
–
+
–
External Termination
DCI
R
VRN
= 2Z
0
= 100Ω
R
VRP
= 2Z
0
= 100Ω
V
TT
= 0.75V for HSTL_II
0.9V for HSTL_II_18
V
TT
= 0.75V for HSTL_II
0.9V for HSTL_II_18
V
REF
=
0.75V for HSTL_II
0.9V for HSTL_II_18
V
REF
=
0.75V for HSTL_II_DCI
0.9V for HSTL_II_DCI_18
V
REF
=
0.75V for HSTL_II_DCI
0.9V for HSTL_II_DCI_18
V
REF
=
0.75V for HSTL_II
0.9V for HSTL_II_18
