Chapter 1: SelectIO Resources
Table 1-41: IOSTANDARD Attributes for Differential HSTL, SSTL, HSUL, or MOBILE_DDR I/O Standards
Attributes
Primitives
IBUFDS, IBUFGDS, IBUFDS_DIFF_OUT,
IBUFGDS_DIFF_OUT, OBUFDS, or OBUFTDS
IOBUFDS or IOBUFDS_DIFF_OUT
HP I/O Banks HR I/O Banks HP I/O Banks HR I/O Banks
IOSTANDARD
DIFF_HSTL_I DIFF_HSTL_I N/A N/A
DIFF_HSTL_I_18 DIFF_HSTL_I_18 N/A N/A
DIFF_HSTL_I_DCI N/A N/A N/A
DIFF_HSTL_I_DCI_18 N/A N/A N/A
DIFF_HSTL_II DIFF_HSTL_II DIFF_HSTL_II DIFF_HSTL_II
DIFF_HSTL_II_18 DIFF_HSTL_II_18 DIFF_HSTL_II_18 DIFF_HSTL_II_18
DIFF_HSTL_II_DCI N/A DIFF_HSTL_II_DCI N/A
DIFF_HSTL_II_DCI_18 N/A DIFF_HSTL_II_DCI_18 N/A
DIFF_HSTL_II_T_DCI N/A DIFF_HSTL_II_T_DCI N/A
DIFF_HSTL_II_T_DCI_18 N/A DIFF_HSTL_II_T_DCI_18 N/A
DIFF_SSTL12 N/A DIFF_SSTL12 N/A
DIFF_SSTL12_DCI N/A N/A N/A
N/A N/A DIFF_SSTL12_T_DCI N/A
N/A DIFF_SSTL135_R N/A DIFF_SSTL135_R
DIFF_SSTL135 DIFF_SSTL135 DIFF_SSTL135 DIFF_SSTL135
DIFF_SSTL135_DCI N/A N/A N/A
N/A N/A DIFF_SSTL135_T_DCI N/A
N/A DIFF_SSTL15_R N/A DIFF_SSTL15_R
DIFF_SSTL15 DIFF_SSTL15 DIFF_SSTL15 DIFF_SSTL15
DIFF_SSTL15_DCI N/A N/A N/A
N/A N/A DIFF_SSTL15_T_DCI N/A
DIFF_SSTL18_I DIFF_SSTL18_I N/A N/A
DIFF_SSTL18_I_DCI N/A N/A N/A
DIFF_SSTL18_II DIFF_SSTL18_II DIFF_SSTL18_II DIFF_SSTL18_II
DIFF_SSTL18_II_DCI N/A DIFF_SSTL18_II_DCI N/A
N/A N/A DIFF_SSTL18_II_T_DCI N/A
DIFF_HSUL_12 DIFF_HSUL_12 DIFF_HSUL_12 DIFF_HSUL_12
DIFF_HSUL_12_DCI N/A DIFF_HSUL_12_DCI N/A
N/A DIFF_MOBILE_DDR N/A DIFF_MOBILE_DDR
