CLUTCH
5-46
Removing the pull lever shaft
Order Job/Parts to remove Q’ty Remarks
1 Circlip 1
2 Pull lever shaft 1
3 Oil seal 1
4 Bearing 1
5 Bearing 1
For installation, reverse the removal proce-
dure.
LS
New
E
4
5
2
New
1
3
LS
