Yamaha XVS1300A 2007 - Page 266

CRANKCASE
5-67
Separating the crankcase
Order Job/Parts to remove Q’ty Remarks
1 Oil baffle plate 1 1
2 Left crankcase 1
3 Dowel pin 2
4 Joint pipe 1 1
5 Joint pipe 2 1
6 Oil baffle plate 2 1
7Gasket 1
8 Right crankcase 1
For installation, reverse the removal proce-
dure.
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
36 Nm (3.6 m
•
kg, 25 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
LT
LT
LT
LT
LT
LT
New
New
New
New
New
LS
LS
LT
LS
LS
1
(5)
2
3
(19)
7
3
4
5
6
8
