CRANKCASE
5-68
Removing the oil seal and bearings
Order Job/Parts to remove Q’ty Remarks
Oil/water pump assembly Refer to “OIL PUMP” on page 5-71.
Crankshaft Refer to “CRANKSHAFT” on page 5-74.
Transmission Refer to “TRANSMISSION” on page 5-79.
1 Bearing retainer 2
2 Oil seal 1
3 Bearing 7
4 Oil nozzle 2
For installation, reverse the removal proce-
dure.
New
LT
LT
LS
LT
LT
E
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
LT
E
New
LS
E
E
New
LS
E
1
1
3
2
3
3
3
3
4
4
To Next Page
