FUEL TANK
7-3
Removing the rollover valve
Order Job/Parts to remove Q’ty Remarks
Fuel tank/Side panels Refer to “FUEL TANK” on page 7-1.
Front cylinder covers Refer to “ENGINE REMOVAL” on page 5-1.
1 Fuel tank breather hose 1
2
Fuel tank breather hose (hose joint to rollover
valve)
1
3 Rollover valve 1
For installation, reverse the removal proce-
dure.
1
2
3
To Next Page
