SIGNALING SYSTEM
8-24
NG →
OK ↓
The brake light fails to come on.
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
The turn signal light, turn signal indicator light or both fail to blink.
NG →
OK ↓
NG →
OK ↓
3. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or repair the signaling
system’s wiring.
This circuit is OK.
1. Check the brake light bulb and
socket.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page
8-86.
Replace the brake light bulb, socket or
both.
2. Check the front brake light switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the front brake light switch.
3. Check the rear brake light switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the rear brake light switch.
4. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or repair the signaling
system’s wiring.
This circuit is OK.
1. Check the turn signal light bulbs
and sockets.
Refer to “CHECKING THE BULBS
AND BULB SOCKETS” on page
8-86.
Replace the turn signal light bulb(s), sock-
et(s) or both.
2. Check the turn signal switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
The turn signal switch is faulty. Replace
the left handlebar switch.
To Next Page
