SIGNALING SYSTEM
8-25
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
The neutral indicator light fails to come on.
NG →
OK ↓
NG →
OK ↓
NG →
OK ↓
The oil level warning light fails to come on.
NG →
OK ↓
3. Check the hazard switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
The hazard switch is faulty. Replace the
right handlebar switch.
4. Check the turn signal relay.
Refer to “CHECKING THE RE-
LAYS” on page 8-91.
Replace the turn signal relay.
5. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or repair the signaling
system’s wiring.
Replace the meter assembly.
1. Check the neutral switch.
Refer to “CHECKING THE
SWITCHES” on page 8-83.
Replace the neutral switch.
2. Check the relay unit (diode).
Refer to “CHECKING THE DI-
ODES” on page 8-93.
Replace the relay unit.
3. Check the entire signaling system’s
wiring.
Refer to “CIRCUIT DIAGRAM” on
page 8-21.
Properly connect or repair the signaling
system’s wiring.
Replace the meter assembly.
1. Check the oil level switch.
Refer to “CHECKING THE OIL
LEVEL SWITCH” on page 8-98.
Replace the oil level switch.
To Next Page
