Yamaha XVS1300A 2007 - Page 42

TIGHTENING TORQUES
2-17
Drain cock bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant delivery pipe bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil/water pump driven sprocket
bolt
M6 1 15 Nm (1.5 m·kg, 11 ft·lb)
Oil filter cartridge M20 1 17 Nm (1.7 m·kg, 12 ft·lb)
Oil filter cartridge union bolt M20 1 70 Nm (7.0 m·kg, 50 ft·lb)
Oil level switch bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Engine oil drain bolt M14 1 43 Nm (4.3 m·kg, 31 ft·lb)
Oil delivery pipe 1 bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil delivery pipe 2 bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil delivery pipe 3 bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil/water pump drive chain guide
bolt
M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Intake air pressure sensor bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Intake manifold joint bolt M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)
Throttle body bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Left side cover bracket bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Exhaust pipe nut M8 4 20 Nm (2.0 m·kg, 14 ft·lb)
Exhaust pipe cover screw clamp M6 6 6 Nm (0.6 m·kg, 4.3 ft·lb)
See
NOTE.
Rear cylinder exhaust pipe bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Exhaust pipe band bolt M8 2 12 Nm (1.2 m·kg, 8.7 ft·lb)
Muffler band bolt M8 1 12 Nm (1.2 m·kg, 8.7 ft·lb)
O
2
sensor
M18 1 44 Nm (4.4 m·kg, 32 ft·lb)
Muffler bracket and frame bolt M10 3 53 Nm (5.3 m·kg, 38 ft·lb)
Muffler bracket and muffler bolt M10 2 35 Nm (3.5 m·kg, 25 ft·lb)
Crankcase stud bolt M12 6 15 Nm (1.5 m·kg, 11 ft·lb)
Left crankcase bolt M6 19 10 Nm (1.0 m·kg, 7.2 ft·lb)
Right crankcase bolt M10 3 36 Nm (3.6 m·kg, 25 ft·lb)
Generator cover bolt M6 10 10 Nm (1.0 m·kg, 7.2 ft·lb)
Crankshaft end screw M36 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Timing mark accessing screw M14 1 6 Nm (0.6 m·kg, 4.3 ft·lb)
Stator coil bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Crankshaft position sensor/sta-
tor assembly lead holder bolt
M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Crankshaft position sensor bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant delivery cover 1 bolt M6 9 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant delivery cover 2 bolt M6 4 10 Nm (1.0 m·kg, 7.2 ft·lb)
Oil baffle plate 1 bolt M6 7 10 Nm (1.0 m·kg, 7.2 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
LT
LT
LT
E
LT
LT
LT
LT
LT
LT
