Yamaha XVS1300A 2007 - Page 43

TIGHTENING TORQUES
2-18
Oil baffle plate 2 bolt M6 3 10 Nm (1.0 m·kg, 7.2 ft·lb)
Crankcase bearing retainer bolt M6 4 12 Nm (1.2 m·kg, 8.7 ft·lb)
Primary drive gear bearing plate
bolt
M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Starter clutch bolt M8 6 24 Nm (2.4 m·kg, 17 ft·lb)
Primary drive gear cover bolt M6 12 10 Nm (1.0 m·kg, 7.2 ft·lb)
Primary drive gear nut M18 1 100 Nm (10.0 m·kg, 72 ft·lb)
Use the
lock
washer.
Clutch cover bolt M6 8 10 Nm (1.0 m·kg, 7.2 ft·lb)
Clutch cable holder bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Damper cover bolt M6 6 7 Nm (0.7 m·kg, 5.1 ft·lb)
Clutch boss nut M20 1 125 Nm (12.5 m·kg, 90 ft·lb)
Stake.
Clutch spring plate retainer bolt M6 6 8 Nm (0.8 m·kg, 5.8 ft·lb)
Shift shaft spring stopper M8 1 22 Nm (2.2 m·kg, 16 ft·lb)
Neutral switch M10 1 20 Nm (2.0 m·kg, 14 ft·lb)
Speed sensor bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Starter motor bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Starter motor lead nut M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Radiator filler pipe bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front cylinder thermostat inlet
pipe 1 bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Front cylinder thermostat inlet
pipe 2 bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Rear cylinder thermostat inlet
pipe 1 bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Rear cylinder thermostat inlet
pipe 2 bolt
M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Rear cylinder thermostat inlet
pipe 2 bolt
M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Thermostat cover inlet pipe bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant temperature sensor M12 1 18 Nm (1.8 m·kg, 13 ft·lb)
Coolant reservoir bolt M6 1 7 Nm (0.7 m·kg, 5.1 ft·lb)
Radiator outlet pipe bolt M6 1 10 Nm (1.0 m·kg, 7.2 ft·lb)
Coolant drain bolt M12 1 2 Nm (0.2 m·kg, 1.4 ft·lb)
Radiator bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)
Item
Thread
size
Q’ty Tightening torque Remarks
LT
LT
LT
LT
E
E
LT
LT
LT
LT
LT
