4.3 Start-Up Flowcharts
These flowcharts summarize steps required to start the drive. Use the flowcharts to determine the most appropriate start-up
method for a given application. The charts are quick references to help familiarize the user with start-up procedures.
Note:
1. Refer to Application Selection on page 134 to set up the drive using one of the Application Presets.
2. Function availability differs for drive models 4A0930 and 4A1200. Refer to Parameter List on page 249 for details.
Flowchart Subchart Objective Page
A – Basic start-up procedure and motor tuning 128
–
A-1 Simple motor setup using V/f mode 129
A-2 High-performance operation using Open Loop Vector or Closed Loop Vector motor control 130
A-3 Setting up the drive to run a permanent magnet (PM) motor 131
4.3 Start-Up Flowcharts
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
127
4
Start-Up Programming & Operation

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
