No.
(Addr.
Hex)
Name LCD Display Description
Analog
Output Level
Unit
U2-15
(07E0)
Run Speed after Soft
Starter at Previous
Fault
SFS Output
Displays the run speed after a soft start when a previous fault
occurred. Displayed as in U1-16.
No signal
output available
0.01 Hz
U2-16
(07E1)
Motor q-Axis Current at
Previous Fault
Motor Iq Current
Displays the q-Axis current for the motor at the previous fault.
Displayed as in U6-01.
No signal
output available
0.1%
U2-17
(07E2)
Motor d-Axis Current at
Previous Fault
Motor Id Current
Displays the d-Axis current for the motor at the previous fault.
Displayed as in U6-02.
No signal
output available
0.1%
U2-19
(07E4)
Rotor Deviation at
Previous Fault
d-q Axis Dev Err
Displays the degree of rotor deviation when the most recent
fault occurred. Displayed as in U6-10.
No signal
output available
0.1 deg
U2-20
(008E)
Heatsink Temperature at
Previous Fault
Actual Fin Temp
Displays the temperature of the heatsink when the most recent
fault occurred. Displayed as in U4-08.
No signal
output available
1 °C
U2-27
(07FA)
Motor Temperature at
Previous Fault (NTC)
Moter temp (NTC)
Displays the temperature of the motor when the most recent
fault occurred. Displayed as in U4-32.
Note: This monitor is only displayed in models
4A0930 and 4A1200.
No signal
output available
1 °C
U2-28
(07FC)
Malfunctioned Module Fault Axis
Display the module where the previous fault occurred at a
decimal number.
Note: This monitor is only displayed in models
4A0930 and 4A1200.
No signal
output available
<1> Display is in the following units:
2A0004 to 2A0040, 4A0002 to 4A0023, and 5A0007 to 5A0017: 0.01 A units.
2A0056 to 2A0415, 4A0031 to 4A0675, and 5A0022 to 5A0242: 0.1 A units.
4A0930 and 4A1200: 1 A units.
<2>
The values of U1-03, U2-05, and U4-13 are displayed on the digital operator in units of amperes. When those monitors are checked using
MEMOBUS/Modbus communications, the monitor values in MEMOBUS/Modbus communications are displayed as: numeric value / 8192 × drive
rated current (A) from the condition “192 (maximum value) = drive rated current (A)”
u
U3: Fault History
No.
(Addr.
Hex)
Name LCD Display Description
Analog
Output Level
Unit
U3-01 to
U3-04
(0090 to
0093
(0800 to
0803))
1st to 4th Most Recent
Fault
Fault Message o
Displays the first to the fourth most recent faults.
No signal
output available
U3-05 to
U3-10
(0804 to
0809)
5th to 10th Most Recent
Fault
Fault Message o
Displays the fifth to the tenth most recent faults.
After ten faults, data for the oldest fault is deleted. The most
recent fault appears in U3-01, with the next most recent fault
appearing in U3-02. The data is moved to the next monitor
parameter each time a fault occurs.
No signal
output available
U3-11 to
U3-14
(0094 to
0097
(080A to
080D))
Cumulative Operation
Time at 1st to 4th Most
Recent Fault
Elapsed Time o
Displays the cumulative operation time when the first to the
fourth most recent faults occurred.
No signal
output available
1 h
U3-15 to
U3-20
(080E to
0813)
Cumulative Operation
Time
at 5th to 10th Most
Recent Fault
Elapsed Time o
Displays the cumulative operation time when the fifth to the
tenth most recent faults occurred. No signal
output available
1 h
B.13 U: Monitors
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
323
B
Parameter List
