H3 Multi-Function Analog Input Settings
H3-oo Setting
Function LCD Display Description When Output Is 100% Page
9
Output frequency
lower limit level
Ref Lower Limit
10 V = E1-04 (maximum output frequency)
–
B PID feedback PID Feedback1 10 V = 100% –
C PID setpoint PID Set Point 10 V = 100% –
D Frequency bias Freq Ref Bias 2 10 V = E1-04 (maximum output frequency) –
E
Motor temperature
(PTC input)
Motor PTC
10 V = 100%
–
F Through mode Not Used
Select this setting when the terminal is not used or when using the terminal
in the pass-through mode.
–
10 Forward torque limit Fwd Torque Limit 10 V = Motor rated torque –
11 Reverse torque limit Rev Torque Limit 10 V = Motor rated torque –
12
Regenerative torque
limit
Regen Torq Limit
10 V = Motor rated torque
–
13
Torque Limit Using
Torque Reference/
Speed Control
Torque Reference
10 V = Motor rated torque
–
14 Torque compensation Torque Comp 10 V = Motor rated torque –
15 General torque limit Torque Limit 10 V = Motor rated torque –
16
Differential PID
feedback
PID Feedback 2
10 V = 100%
–
17
Motor Thermistor
(NTC)
Moter temp (NTC)
10 V = -9 °C
0 V = +234 °C
Note: This setting is only available in models 4A0930 and
4A1200.
–
1F Through mode Not Used
Select this setting when the terminal is not used or when using the terminal
in the pass-through mode.
–
30 to 32
DriveWorksEZ
analog input 1 to 3
–
Output is determined by the function selected using DWEZ.
–
u
H4: Analog Outputs
No.
(Addr.
Hex)
Name LCD Display Description Values Page
H4-01
(041D)
Multi-Function Analog
Output Terminal FM
Monitor Selection
Term FM FuncSel
Selects the data to be output through multi-function analog
output terminal FM.
Set the desired monitor parameter to the digits available in
Uo-oo.
For example, enter “103” for U1-03.
Default: 102
Range: 000 to
999
157
H4-02
(041E)
Multi-Function Analog
Output Terminal FM
Gain
Terminal FM Gain
Sets the signal level at terminal FM that is equal to 100% of the
selected monitor value.
Default: 100.0%
Min.: -999.9
Max.: 999.9
158
H4-03
(041F)
Multi-Function Analog
Output Terminal FM
Bias
Terminal FM Bias
Sets the signal level at terminal FM that is equal to 0% of the
selected monitor value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
158
H4-04
(0420)
Multi-Function Analog
Output Terminal AM
Monitor Selection
Terminal AM Sel
Selects the data to be output through multi-function analog
output terminal AM.
Set the desired monitor parameter to the digits available in
Uo-oo.
For example, enter “103” for U1-03.
Default: 103
Range: 000 to
999
157
H4-05
(0421)
Multi-Function Analog
Output Terminal AM
Gain
Terminal AM Gain
Sets the signal level at terminal AM that is equal to 100% of
the selected monitor value.
Default: 50.0%
Min.: -999.9
Max.: 999.9
158
H4-06
(0422)
Multi-Function Analog
Output Terminal AM
Bias
Terminal AM Bias
Sets the signal level at terminal AM that is equal to 0% of the
selected monitor value.
Default: 0.0%
Min.: -999.9
Max.: 999.9
158
B.7 H Parameters: Multi-Function Terminals
296
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
