YASKAWA A1000 Series User Manual

B.4 d: References
Reference parameters set the various frequency reference values during operation.
u
d1: Frequency Reference
No.
(Addr.
Hex)
Name LCD Display Description Values Page
d1-01
(0280)
Frequency Reference 1 Reference 1
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-02
(0281)
Frequency Reference 2 Reference 2
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-03
(0282)
Frequency Reference 3 Reference 3
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-04
(0283)
Frequency Reference 4 Reference 4
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-05
(0284)
Frequency Reference 5 Reference 5
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-06
(0285)
Frequency Reference 6 Reference 6
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-07
(0286)
Frequency Reference 7 Reference 7
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-08
(0287)
Frequency Reference 8 Reference 8
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-09
(0288)
Frequency Reference 9 Reference 9
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
d1-10
(028B)
Frequency Reference 10 Reference 10
Sets the frequency reference for the drive. Setting units are
determined by parameter o1-03.
Note: The value set to o1-03 is changed to 1 and the
unit is changed to percentage automatically
when A1-02 is set to 6 or 7.
Default: 0.00 Hz
Min.: 0.00
Max.:
400.00
<1>
<2>
145
B.4 d: References
266
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
