YASKAWA A1000 Series - O3: Copy Function; O4: Maintenance Monitor Settings

No.
(Addr.
Hex)
Name LCD Display Description Values Page
o2-04
(0508)
Drive Model Selection Inverter Model #
Enter the drive model. Setting required only if installing a new
control board.
Default:
Determined by
drive capacity
–
o2-05
(0509)
Frequency Reference
Setting Method
Selection
Oper Ref Method
0: Disabled
1: Enabled
0: ENTER key must be pressed to enter a frequency reference.
1:
ENTER key is not required. The frequency reference can be
adjusted using the up and down arrow keys only.
Default: 0
Range: 0, 1
–
o2-06
(050A)
Operation Selection
when Digital Operator is
Disconnected
Oper Discon Det
0: Disabled
1: Enabled
0: The drive continues operating if the digital operator is
disconnected.
1: An oPr fault is triggered and the motor coasts to stop.
Default: 1
Range: 0, 1
–
o2-07
(0527)
Motor Direction at
Power Up when Using
Operator
For/RevSel@PwrUp
0: Forward
1: Reverse
0: Forward
1: Reverse
This parameter requires assigning drive operation to the digital
operator.
Default: 0
Range: 0, 1
–
o2-09
(050D)
– –
Factory use.
– –
o2-19
(061F)
<1>
Selection of Parameter
Write during Uv
ParameterSet Sel
0: Disabled
1: Enabled
Selects whether parameter settings can be changed during a DC
bus undervoltage condition. To be used with 24 V Power
Supply option (PS-A10L, PS-A10H) revision B or later.
0: Disabled
1: Enabled
Note: Enabling
this function may trigger a CPF06 fault
when used with a 24 V Power Supply option
revision earlier than B, as the parameter changes
might not occur correctly.
Default: 0
Range: 0, 1
–
<1> Available in drive software versions PRG: 1019 and later.
u
o3: Copy Function
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o3-01
(0515)
Copy Function Selection
COPY SELECT
0: COPY SELECT
1: INV→OP READ
2: OP→INV WRITE
3: OP←→INV
VERIFY
0: Copy select
1:
INV → OP READ (Read parameters from the drive, saving
them onto the digital operator).
2: OP → INV WRITE (Copy parameters from the digital
operator, writing them to the drive).
3: OP → INV VERIFY (Verify that parameter settings match
the data saved on the operator).
To read the drive parameter settings into the digital operator,
set o3-02 to 1 (to allow reading).
Default: 0
Range: 0 to 3
–
o3-02
(0516)
Copy Allowed Selection
Read Allowable
0: Disabled
1: Enabled
Selects whether the read operation (o3-01 = 1) is enabled or
disabled.
0: Read operation prohibited
1: Read operation allowed
Default: 0
Range: 0, 1
–
u
o4: Maintenance Monitor Settings
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o4-01
(050B)
Cumulative Operation
Time Setting
DrvElapsTimeCnt
Sets the value for the cumulative operation time of the drive in
units of 10 h.
Default: 0
Min.: 0
Max.: 9999
–
o4-02
(050C)
Cumulative Operation
Time Selection
ElapsTimeCntSet
0: Power-On Time
1: Running Time
0: Logs power-on time
1: Logs operation time when the drive output is active (output
operation time).
Default: 0
Range: 0, 1
–
o4-03
(050E)
Cooling Fan Operation
Time Setting
FanElapsTimeCn
Sets the value of the fan operation time monitor U4-03 in units
of 10 h.
Default: 0
Min.: 0
Max.: 9999
–
o4-05
(051D)
Capacitor Maintenance
Setting
BusCap Maint Set
Sets the point at which the cumulative timing for the main
circuit capacitor maintenance starts.
View monitor U4-05 to determine when the capacitors may
require replacement.
Default: 0%
Min.: 0
Max.: 150
–
B.10 o: Operator-Related Settings
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
313
B
Parameter List
