YASKAWA A1000 Series User Manual

u
Quick Reference
Easily Set Parameters for Specific Applications
Preset parameter defaults are available for setting up applications. Refer to Application Selection on
page 134.
Run a Motor One Frame Larger
This drive can operate a motor one frame size larger when running variable torque loads such as fans and pumps. Refer to C6-01: Drive Duty Mode
Selection
on page 144.
Drive a Synchronous PM Motor
The drive can operate synchronous PM motors. Refer to
Subchart A-3: Operation with Permanent
Magnet Motors on page 131.
Perform Auto-Tuning
Automatic tuning sets motor parameters. Refer to
Auto-Tuning on page 164.
Maintenance Check Using Drive Monitors
Use drive monitors to check if fans, capacitors, or other components require maintenance. Refer to Performance Life Monitors Maintenance
Monitors on page 217.
Fault Display and Troubleshooting
Refer to Drive Alarms, Faults, and Errors on page 178.
Standards Compliance
Refer to European Standards on page 330 and Refer to UL and CSA Standards
on page 340.
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
3

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
