No.
(Addr.
Hex)
Name Description
Analog
Output Level
Unit
U1-25
(004D)
Software Number
(Flash)
CPU 1 SW Number
FLASH ID No signal
output available
–
U1-26
(005B)
Software No. (ROM) CPU 2 SW Number
ROM ID No signal
output available
–
U1-27
(07A8)
Message ID (OPR) MessageID (OPR) OPR ID
No signal
output available
–
U1-28
(07A9)
Message ID (INV) MessageID (INV) INV ID
No signal
output available
–
U1-29
(07AA)
Software No. (PWM) CPU 3 SW Number
PWM ID
Note: This monitor is only displayed in models
4A0930 and 4A1200.
No signal
output available
–
<1> Display is in the following units:
2A0004 to 2A0040, 4A0002 to 4A0023, and 5A0007 to 5A0017: 0.01 A units.
2A0056 to 2A0415, 4A0031 to 4A0675, and 5A0022 to 5A0242: 0.1 A units.
4A0930 and 4A1200: 1 A units.
<2>
The values of U1-03, U2-05, and U4-13 are displayed on the digital operator in units of amperes. When those monitors are checked using
MEMOBUS/Modbus communications, the monitor values in MEMOBUS/Modbus communications are displayed as: numeric value / 8192 × drive
rated current (A) from the condition “192 (maximum value) = drive rated current (A)”
<3> Values shown are specific to 200 V class drives. Double the value for 400 V class drives. Multiply the value by 2.875 for 600 V class drives.
<4> In V/f and V/f w/PG control modes, 10 V = drive capacity (kW). In OLV, CLV, OLV/PM, AOLV/PM, and CLV/PM control modes, 10 V = motor
rated power (E2-11) (kW).
u
U2: Fault Trace
No.
(Addr.
Hex)
Name LCD Display Description
Analog
Output Level
Unit
U2-01
(0080)
Current Fault Current Fault
Displays the current fault. No signal
output available
–
U2-02
(0081)
Previous Fault Last Fault
Displays the previous fault. No signal
output available
–
U2-03
(0082)
Frequency Reference at
Previous Fault
Frequency Ref
Displays the frequency reference at the previous fault. No signal
output available
0.01 Hz
U2-04
(0083)
Output Frequency at
Previous Fault
Output Freq
Displays the output frequency at the previous fault. No signal
output available
0.01 Hz
U2-05
(0084)
Output Current at
Previous Fault
Output Current
Displays the output current at the previous fault.
Note: The
unit is expressed in 1 A for models 4A0930
and 4A1200.
No signal
output available
<1>
<2>
U2-06
(0085)
Motor Speed at Previous
Fault
Motor Speed
Displays the motor speed at the previous fault. No signal
output available
0.01 Hz
U2-07
(0086)
Output Voltage at
Previous Fault
Output Voltage
Displays the output voltage at the previous fault. No signal
output available
0.1 Vac
U2-08
(0087)
DC Bus Voltage at
Previous Fault
DC Bus Voltage
Displays the DC bus voltage at the previous fault. No signal
output available
1 Vdc
U2-09
(0088)
Output Power at
Previous Fault
Output kWatts
Displays the output power at the previous fault. No signal
output available
0.1 kW
U2-10
(0089)
Torque Reference at
Previous Fault
Torque Reference
Displays the torque reference at the previous fault. No signal
output available
0.1%
U2-11
(008A)
Input Terminal Status at
Previous Fault
Input Term Sts
Displays the input terminal status at the previous fault.
Displayed as in U1-10.
No signal
output available
–
U2-12
(008B)
Output Terminal Status
at Previous Fault
Output Term Sts
Displays the output status at the previous fault. Displayed as in
U1-11.
No signal
output available
–
U2-13
(008C)
Drive Operation Status
at Previous Fault
Inverter Status
Displays the operation status of the drive at the previous fault.
Displayed as in U1-12.
No signal
output available
–
U2-14
(008D)
Cumulative Operation
Time at Previous Fault
Elapsed time
Displays the cumulative operation time at the previous fault. No signal
output available
1 h
B.13 U: Monitors
322
