YASKAWA A1000 Series - F2: Analog Input Card Settings (AI-A3); F3: Digital Input Card Settings (DI-A3)

No.
(Addr.
Hex)
Name LCD Display Description Values Page
F1-52
(03D4)
<2>
Communication Speed
of Serial Encoder
Selection
Ser Enc Comm Spd
0: 1M/9600bps
1: 500k/19200bps
2: 1M/38400bps
3: 1M/38400bps
Selects the communication speed between the PG-F3 option
and serial encoder.
0: 1M bps/9600 bps (EnDat 2.2/22 / Hiperface)
1: 500k bps/19200 bps (EnDat 2.2/22 / Hiperface)
2: 1M bps/38400 bps (EnDat 2.2/22 / Hiperface)
3: 1M bps/38400 bps (EnDat 2.2/22 / Hiperface)
Note: Parameter
is not available in models 4A0930 and
4A1200.
Default: 0
Range: 0 to 3
–
<1> Default setting is determined by parameter A1-02, Control Method Selection.
<2>
Available in drive software versions PRG: 1018 and later.
u
F2: Analog Input Card Settings (AI-A3)
No.
(Addr.
Hex)
Name LCD Display Description Values Page
F2-01
(038F)
Analog Input Option
Card Operation
Selection
AI Function Sel
0: 3ch Individual
1: 3ch Addition
0: Option card input terminals V1, V2, and V3 replace drive
input terminals A1, A2, and A3.
1:
Input signals to terminals V1, V2, and V3 are added together
to create the frequency reference.
Default: 0
Range: 0, 1
–
F2-02
(0368)
Analog Input Option
Card Gain
AI Input Gain
Sets the gain for the input signal to the analog card.
Default: 100.0%
Min.: -999.9
Max.: 999.9
–
F2-03
(0369)
Analog Input Option
Card Bias
AI Input Bias
Sets the bias for the input signal to the analog card.
Default: 0.0%
Min.: -999.9
Max.: 999.9
–
u
F3: Digital Input Card Settings (DI-A3)
No.
(Addr.
Hex)
Name LCD Display Description Values Page
F3-01
(0390)
Digital Input Option
Card Input Selection
DI Function Sel
0: BCD 1%
1: BCD 0.1%
2: BCD 0.01%
3: BCD 1 Hz
4: BCD 0.1 Hz
5: BCD 0.01 Hz
6:
BCD(5DG) 0.01 Hz
7: Binary
0: BCD, 1% units
1: BCD, 0.1% units
2: BCD, 0.01% units
3: BCD, 1 Hz units
4: BCD, 0.1 Hz units
5: BCD, 0.01 Hz units
6: BCD customized setting (5-digit), 0.02 Hz units
7: Binary input
The unit and the setting range are determined by F3-03.
F3-03 = 0: 255/100% (-255 to +255)
F3-03 = 1: 40961/100% (-4095 to +4095)
F3-03 = 2: 30000/100% (-33000 to +33000)
When the digital operator units are set to be displayed in Hz or
user-set units (o1-03 = 2 or 3), the units for F3-01 are
determined by parameter o1-03.
Default: 0
Range: 0 to 7
–
F3-03
(03B9)
Digital Input Option DI-
A3 Data Length
Selection
Data length Sel
0: 8bit
1: 12bit
2: 16bit
0: 8 bit
1: 12 bit
2: 16 bit
Default: 2
Range: 0 to 2
–
B.6 F: Option Settings
280
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
