F7: Communication Option Card Settings (SI-EM3, SI-EN3, SI-EP3)
F7 parameters are used for EtherNet/IP, Modbus TCP/IP, and PROFINET options. Other parameters in the F7 group are used
for communication-protocol-specific settings. For more details on a specific option card, refer to the instruction manual for
the option.
No.
(Addr.
Hex)
Name LCD Display Description Values Page
F7-01
(03E5)
<1>
IP Address 1 IP Address 1 Sets the most significant octet of network static IP address.
Default: 192
Range: 0 to 255
–
F7-02
(03E6)
<1>
IP Address 2 IP Address 2
Sets the second most significant octet of network static IP
address.
Default: 168
Range: 0 to 255
–
F7-03
(03E7)
<1>
IP Address 3 IP Address 3
Sets the third most significant octet of network static IP
address.
Default: 1
Range: 0 to 255
–
F7-04
(03E8)
<1>
IP Address 4 IP Address 4
Sets the fourth most significant octet of network static IP
address.
Default: 20
Range: 0 to 255
–
F7-05
(03E9)
Subnet Mask 1 Subnet Mask 1 Sets the most significant octet of network static Subnet Mask.
Default: 255
Range: 0 to 255
–
F7-06
(03EA)
Subnet Mask 2 Subnet Mask 2
Sets the second most significant octet of network static Subnet
Mask.
Default: 255
Range: 0 to 255
–
F7-07
(03EB)
Subnet Mask 3 Subnet Mask 3
Sets the third most significant octet of network static Subnet
Mask.
Default: 255
Range: 0 to 255
–
F7-08
(03EC)
Subnet Mask 4 Subnet Mask 4
Sets the fourth most significant octet of network static Subnet
Mask.
Default: 0
Range: 0 to 255
–
F7-09
(03ED)
Gateway Address 1 Gateway IP Add 1 Sets the most significant octet of network Gateway address.
Default: 192
Range: 0 to 255
–
F7-10
(03EE)
Gateway Address 2 Gateway IP Add 2
Sets the second most significant octet of network Gateway
address.
Default: 168
Range: 0 to 255
–
F7-11
(03EF)
Gateway Address 3 Gateway IP Add 3
Sets the third most significant octet of network Gateway
address.
Default: 1
Range: 0 to 255
–
F7-12
(03F0)
Gateway Address 4 Gateway IP Add 4
Sets the fourth most significant octet of network Gateway
address.
Default: 1
Range: 0 to 255
–
F7-13
(03F1)
Address Mode at Startup
IP Add Mode Sel
0: User Defined
1: BOOTP
2: DHCP
Select the option address setting method
0: Static
<2>
1: BOOTP
2: DHCP
Default: 2
Range: 0 to 2
–
F7-14
(03F2)
Duplex Mode Selection
Duplex Select
0: Half/Half
1: Auto/Auto
2: Full/Full
3: Half/Auto
4: Half/Full
5: Auto/Half
6: Auto/Full
7: Full/Half
8: Full/Auto
Selects duplex mode setting.
0: Half duplex forced
1: Auto-negotiate duplex mode and communication speed
2: Full duplex forced
3:
Half duplex forced (port 1)/Auto-negotiate duplex mode and
communication speed (port 2)
4: Half duplex forced (port 1)/Full duplex forced (port 2)
5: Auto-negotiate duplex mode and communication speed
(port 1)/Half duplex forced (port 2)
6: Auto-negotiate duplex mode and communication speed
(port 1)/Full duplex forced (port 2)
7: Full duplex forced (port 1)/Half duplex forced (port 2)
8: Full duplex forced (port 1)/Auto-negotiate duplex mode and
communication speed (port 2)
Default: 1
Range: 0 to 8
–
F7-15
(03F3)
Communication Speed
Selection
Baud Rate
10: 10/10 Mbps
100: 100/100 Mbps
101: 10/100 Mbps
102: 100/10 Mbps
Sets the communication speed
10: 10 Mbps
100: 100 Mbps
101: 10 Mbps (port 1)/100 Mbps (port 2)
102: 100 Mbps (port 1)/10 Mbps (port 2)
Default: 10
Range: 10 to 102
–
F7-16
(03F4)
Communication Loss
Time Out
CommLoss Tout
Sets the time out value for communication loss detection in
tenths of a second. A value of 0 disables the connection time
out.
Example: An entered value of 100 represents 10.0 seconds.
Default: 0.0 s
Min.: 0.0
Max.: 30.0
–
B.6 F: Option Settings
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
285
B
Parameter List
