No.
(Addr.
Hex)
Name LCD Display Description Values Page
F7-17
(03F5)
EtherNet/IP Speed
Scaling Factor
EN Speed Scale
Sets the scaling factor for the speed monitor in EtherNet/IP
Class ID 2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-18
(03F6)
EtherNet/IP Current
Scaling Factor
EN Current Scale
Sets the scaling factor for the output current monitor in
EtherNet/IP Class ID 2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-19
(03F7)
EtherNet/IP Torque
Scaling Factor
EN Torque Scale
Sets the scaling factor for the torque monitor in EtherNet/IP
Class ID 2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-20
(03F8)
EtherNet/IP Power
Scaling Factor
EN Power Scale
Sets the scaling factor for the power monitor in EtherNet/IP
Class ID 2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-21
(03F9)
EtherNet/IP Voltage
Scaling Factor
EN Voltage Scale
Sets the scaling factor for the voltage monitor in EtherNet/IP
Class ID 2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-22
(03FA)
EtherNet/IP Time
Scaling
EN Time Scale
Sets the scaling factor for the time monitor in EtherNet/IP Class
ID 2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-23 to
F7-27
(03FB to
03FF)
F7-28 to
F7-32
(0370 to
0374)
Dynamic Output
Assembly Parameters
–
Parameters used in Output Assembly 116. Each parameter
contains a MEMOBUS/Modbus address. The value received
for
Output Assembly 116 will be written to this corresponding
MEMOBUS/Modbus address. A MEMOBUS/Modbus
address value of 0 means that the value received for Output
Assembly 116 will not be written to any MEMOBUS/Modbus
register.
Default: 0 –
F7-33 to
F7-42
(0375 to
037E)
Dynamic Input
Assembly Parameters
–
Parameters used in Input Assembly 166. Each parameter
contains a MEMOBUS/Modbus address. The value sent for
Input Assembly 166 will be read from this corresponding
MEMOBUS/Modbus address. A MEMOBUS/Modbus
address value of 0 means that the value sent for Input Assembly
166 is not defined by the user, therefore the option default
register value will be returned.
Default: 0 –
F7-60
(0780)
PZD1 Write PZD1 Write
Sets MEMOBUS/Modbus address for PZD1 Write (PPO
Write).
Values 0 to 2 enable the PZD1 Write as STW.
Default: 0
Min.: 0
Max.: FFFF
–
F7-61
(0781)
PZD2 Write PZD2 Write
Sets MEMOBUS/Modbus address for PZD2 Write (PPO
Write).
Values 0 to 2 enable the PZD2 Write as HSW.
Default: 0
Min.: 0
Max.: FFFF
–
F7-62
(0782)
PZD3 Write PZD3 Write
Sets MEMOBUS/Modbus address for PZD3 Write (PPO
Write).
Values 0 to 2 disable the PZD3 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-63
(0783)
PZD4 Write PZD4 Write
Sets MEMOBUS/Modbus address for PZD4 Write (PPO
Write).
Values 0 to 2 disable the PZD4 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-64
(0784)
PZD5 Write PZD5 Write
Sets MEMOBUS/Modbus address for PZD5 Write (PPO
Write).
Values 0 to 2 disable the PZD5 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-65
(0785)
PZD6 Write PZD6 Write
Sets MEMOBUS/Modbus address for PZD6 Write (PPO
Write).
Values 0 to 2 disable the PZD6 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-66
(0786)
PZD7 Write PZD7 Write
Sets MEMOBUS/Modbus address for PZD7 Write (PPO
Write).
Values 0 to 2 disable the PZD7 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-67
(0787)
PZD8 Write PZD8 Write
Sets MEMOBUS/Modbus address for PZD8 Write (PPO
Write).
Values 0 to 2 disable the PZD8 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-68
(0788)
PZD9 Write PZD9 Write
Sets MEMOBUS/Modbus address for PZD9 Write (PPO
Write).
Values 0 to 2 disable the PZD9 Write.
Default: 0
Min.: 0
Max.: FFFF
–
F7-69
(0789)
PZD10 Write PZD10 Write
Sets MEMOBUS/Modbus address for PZD10 Write (PPO
Write).
Values 0 to 2 disable the PZD10 Write.
Default: 0
Min.: 0
Max.: FFFF
–
B.6 F: Option Settings
286
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
