B.1 A: Initialization Parameters
Table B.1
Symbols and Icons Used in Parameter Descriptions
Symbol Description
Parameter can be changed during run.
Motor 2
Refers to a second motor when the drive is operating two motors. Use multi-function input terminals to switch
between motors.
The A parameter group creates the operating environment for the drive. This includes the parameter Access Level, Motor
Control Method, Password, User Parameters and more.
u
A1: Initialization
No.
(Addr.
Hex)
Name LCD Display Description Values Page
A1-00
(0100)
<1>
Language Selection
Select Language
0: English
1:
(Japanese)
2: Deutsch
3: Français
4: Italiano
5: Español
6: Portuguêse
7:
8: Czech
9: Russian
10: Turkish
11: Polish
12: Greek
0: English
1: Japanese
2: German
3: French
4: Italian
5: Spanish
6: Portuguese
7: Chinese
8: Czech
9: Russian
10: Turkish
11: Polish
12: Greek
Note: Settings
8 to 12 can only be selected from an LCD
operator with version REV: F or later. The
version is listed on the back of the operator.
Default: 0
Range: 0 to 12
<2>
–
A1-01
(0101)
<3>
Access Level Selection
Access Level
0: Operation Only
1: User Parameters
2: Advanced Level
0: View and set A1-01 and A1-04. Uo-oo
parameters can also
be viewed.
1: User Parameters (access to a set of parameters selected by the
user, A2-01 to A2-32)
2: Advanced Access (access to view and set all parameters)
Default: 2
Range: 0 to 2
–
A1-02
(0102)
<1>
Control Method
Selection
Control Method
0: V/f Control
1: V/f with PG
2: Open Loop Vector
3: Closed Loop Vect
5:
PM OpenLoop Vect
6: PM
AdvOpLoopVect
7: PM ClosedLoopVct
0: V/f Control
1: V/f Control with PG
2: Open Loop Vector Control
3: Closed Loop Vector Control
5: Open Loop Vector Control for PM
6: Advanced Open Loop Vector Control for PM
7: Closed Loop Vector Control for PM
Default: 2
Range: 0 to 3;
5 to7
135
A1-03
(0103)
Initialize Parameters
Init Parameters
0: No Initialize
1110: User Initialize
2220: 2-Wire Initial
3330: 3-Wire Initial
5550: Term->Cntrl Int
0: No initialization
1110: User Initialize (parameter values must be stored using
parameter o2-03)
2220: 2-Wire initialization
3330: 3-Wire initialization
5550: oPE04 error reset
Default: 0
Range: 0 to
3330;
5550
135
A1-04
(0104)
Password Enter Password
When the value set into A1-04 does not match the value set into
A1-05, parameters A1-01 through A1-03, A1-06, A1-07, and
A2-01 through A2-32 cannot be changed.
Default: 0000
Min.: 0000
Max.: 9999
–
A1-05
(0105)
Password Setting Select Password
When the value set into A1-04 does not match the value set into
A1-05, parameters A1-01 through A1-03, A1-06, A1-07, and
A2-01 through A2-32 cannot be changed.
Default: 0000
Min.: 0000
Max.: 9999
–
A1-06
(0127)
Application Preset
Application Sel
0: General
1: Pump
2: Conveyor
3: Exhaust Fan
4: Supply Fan
5: Compressor
0: General-purpose
1: Water supply pump
2: Conveyor
3: Exhaust fan
4: HVAC fan
5: Air compressor
Default: 0
Range: 0 to 5
–
A1-07
(0128)
DriveWorksEZ
Function Selection
DWEZ Func Sel
0: Disabled
1: Enabled
2: Terminal Control
0: DWEZ Disabled
1: DWEZ Enabled
2: Digital input (enabled when H1-oo = 9F)
Default: 0
Range: 0 to 2
–
