B.10 o: Operator-Related Settings
The o parameters set up the digital operator displays.
u
o1: Digital Operator Display Selection
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o1-01
(0500)
Drive Mode Unit
Monitor Selection
User Monitor Sel
Switches the display after the power has been turned on.
When using an LED operator, pressing the up arrow key will
display the following data: frequency reference → rotational
direction → output frequency → output current → output
voltage → U1-oo.
Note:
Enter
the “1-oo” portion of “U1-oo” to view
the monitor. Certain monitors are not available
in all control modes.
Default: 106
(Monitor U1-06)
Range: 104 to
813
–
o1-02
(0501)
User Monitor Selection
after Power Up
Power-On Monitor
1: Frequency Ref
2: FWD/REV
3: Output Freq
4: Output Current
5: User Monitor
Selects the information displayed on the digital operator when
the power is turned on.
1: Frequency reference (U1-01)
2: Direction
3: Output frequency (U1-02)
4: Output current (U1-03)
5: User-selected monitor (set by o1-01)
Default: 1
Range: 1 to 5
–
o1-03
(0502)
Digital Operator Display
Selection
Display Unit Sel
0: 0.01 Hz
1: 0.01 %
2: r/min
3: User Units
Sets the units the drive should use to display the frequency
reference and motor speed monitors.
0: 0.01 Hz
1: 0.01% (100% = E1-04)
2:
r/min (calculated using the number of motor poles setting in
E2-04, E4-04, or E5-04)
3: User-selected units (set by o1-10 and o1-11)
Default:
<1>
Range: 0 to 3
–
o1-04
(0503)
V/f Pattern Display Unit
V/f Ptrn Unit
0: Hertz
1: RPM
0: Hz
1: r/min
Default:
<1>
Range: 0, 1
–
o1-05
(0504)
<2>
LCD Contrast Control LCD Contrast
Sets the contrast of the LCD operator.
Default: 3
Min.: 0
Max.: 5
–
o1-10
(0520)
User-Set Display Units
Maximum Value
UserDisp Scaling
These settings define the display values when o1-03 is set to 3.
o1-10
sets the display value that is equal to the maximum output
frequency.
o1-11 sets the position of the decimal position.
Default:
<3>
Range: 1 to
60000
–
o1-11
(0521)
User-Set Display Units
Decimal Display
UserDisp Dec Sel
Default:
<3>
Range: 0 to 3
–
<1> Default setting is determined by parameter A1-02, Control Method Selection.
<2>
Available in drive software versions PRG: 1019 and later.
<3> Default setting is determined by parameter o1-03, Digital Operator Display Selection.
u
o2: Digital Operator Keypad Functions
No.
(Addr.
Hex)
Name LCD Display Description Values Page
o2-01
(0505)
LO/RE Key Function
Selection
LO/RE Key
0: Disabled
1: Enabled
0: Disabled
1: Enabled. LO/RE key switches between LOCAL and
REMOTE operation.
Default: 1
Range: 0, 1
–
o2-02
(0506)
STOP Key Function
Selection
Oper STOP Key
0: Disabled
1: Enabled
0: Disabled. STOP key is disabled in REMOTE operation.
1: Enabled. STOP key is always enabled.
Default: 1
Range: 0, 1
–
o2-03
(0507)
User Parameter Default
Value
User Default Sel
0: No Change
1: Save User Init
2: Clear User Init
0: No change.
1: Set defaults. Saves parameter settings as default values for
a User Initialization.
2:
Clear all. Clears the default settings that have been saved for
a User Initialization.
Default: 0
Range: 0 to 2
–
B.10 o: Operator-Related Settings
312
