Flange Type Model 4A0031
n
Flange Type Exterior and Mounting Dimensions
0.45
[11]
2.36
[60]
5.42
[137.6]
0.05
[1.3]
(2) EXTERNAL
COOLING FANS
(6)-MOUNTING
HOLES FOR
#10 [M5] SCREWS
0.79
[20.0]
0.79
[20.0]
0.11
[3]
0.45
[11]
1.85
[47]
6.57
[167]
0.2
[5]
NOTE: Maximum surrounding air temperature is 50 °C (122 °F)
7.09
[180.0]
6.85
[174]
9.21
[234.0]
2.04
[52]
1.55
[39.3]
3.54
[90]
6.27
[159.2]
6.21
[157.8]
7.91
[201]
5.51
[140.0]
FRONT VIEW
HORIZONTAL MTG DIM
HORIZONTAL MTG DIM
VERTICAL MTG DIM
VERTICAL MTG DIM
AIR
AIR
11.81
[300.0]
11.69
[297]
13.39
[340]
Unit: in. [mm]
Figure 2.15 Model 4A0031
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
