Table C.3 400 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Type
Rated Short Circuit
Braking Current
(kA)
Qty. Type Qty.
4A0002 CR6L-20
100
2 CMS-4 2
4A0004 CR6L-30
4A0005
CR6L-50
4A0007
4A0009
4A0011
4A0018
CR6L-75
2 CMS-5 2
4A0023
4A0031 CR6L-100
4A0038
CR6L-150
4A0044
4A0058 CR6L-200
2
<1>
4A0072
CR6L-250
4A0088
4A0103 CR6L-300
4A0139 CR6L-350
4A0165 CR6L-400
4A0208
CS5F-600
200
4A0250
4A0296
4A0362
CS5F-800
4A0414
4A0515 CS5F-1200
4A0675 CS5F-1500
4A0930 CS5F-1200
4
4A1200 CS5F-1500
<1> Manufacturer does not recommend a specific fuse holder for this fuse. Contact Yaskawa or your nearest sales representative for fuse dimensions.
n
Guarding Against Harmful Materials
When installing IP00/Open Type enclosure drives, use an enclosure that prevents foreign material from entering the drive
from above or below.
n
Grounding
The drive is designed to be used in T-N (grounded neutral point) networks. If installing the drive in other types of grounded
systems, contact your Yaskawa representative for instructions.
u
EMC Guidelines Compliance
This drive is tested according to European standards EN 61800-3:2004+A1:2012.
n
EMC Filter Installation
The following conditions must be met to ensure continued compliance with guidelines. Refer to
EMC Filters on page 337
for EMC filter selection.
Installation Method
Verify the following installation conditions to ensure that other devices and machinery used in combination with this drive
also comply with EMC guidelines.
1.
Install an EMC noise filter to the input side specified by Yaskawa for compliance with European standards.
2.
Place the drive and EMC noise filter in the same enclosure.
