Table C.2 200 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Type
Rated Short Circuit
Braking Current
(kA)
Qty. Type Qty.
2A0004
CR2LS-30
100
2 CM-1A 1
2A0006
2A0008
2A0010
CR2LS-50
2A0012
2A0018 CR2LS-75
2A0021 CR2LS-100
2A0030 CR2L-125
2 CM-2A 12A0040 CR2L-150
2A0056 CR2L-175
2A0069 CR2L-225
2
<1>
2A0081 CR2L-260
2A0110 CR2L-300
2A0138 CR2L-350
2A0169 CR2L-400
2A0211 CR2L-450
2A0250
CR2L-600
2A0312
2A0360 CR2L-600
200
2A0415 CS5F-1200
<1> Manufacturer does not recommend a specific fuse holder for this fuse. Contact Yaskawa or your nearest sales representative for fuse dimensions.
