YASKAWA A1000 Series - Flange Type Models 2 A0056, 4 A0038, and 5 A0017 and 5 A0022

u
Flange Type Models 2A0056, 4A0038, and 5A0017 and 5A0022
n
Flange Type Exterior and Mounting Dimensions
0.05
[1.3]
5.42
[137.6]
2.36
[60]
0.45
[11]
0.79
[20.0]
(2) EXTERNAL
COOLING FANS
(6)-MOUNTING
HOLES FOR
#10 [M5] SCREWS
0.79
[20.0]
0.11
[3]
0.11
[3]
1.85
[47]
7.91
[201]
5.51
[140.0]
1.85
[47]
7.36
[187]
0.2
[5]
AIR
AIR
7.09
[180.0]
6.85
[174]
9.21
[234.0]
Unit: in. [mm]
NOTE: Maximum surrounding air temperature is 50 °C (122 °F)
HORIZONTAL MTG DIM
HORIZONTAL MTG DIM
VERTICAL MTG DIM
VERTICAL MTG DIM
3.54
[90]
11.81
[300.0]
6.21
[157.8]
6.27
[159.2]
11.69
[297]
13.39
[340]
FRONT VIEW
1.55
[39.3]
2.83
[172]
Figure 2.17 Models 2A0056, 4A0038, and 5A0017 and 5A0022
2.2 Flange Type Enclosure (NEMA 12 Backside) Dimensions & Heat Loss
52
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide
