YASKAWA A1000 Series User Manual

A.4 Drive Watt Loss Data
Table A.11
Watt Loss 200 V Class Three-Phase Models
Drive Model
Normal Duty Heavy Duty
Rated Amps
(A)
<3>
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
Rated Amps
(A)
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
2A0004 3.5 18.4 47 66
3.2
<1>
14.8 44 59
2A0006 6.0 31 51 82
5.0
<1>
24 48 72
2A0008 8.0 43 52 95
6.9
<1>
35 49 84
2A0010 9.6 57 58 115
8.0
<1>
43 52 95
2A0012 12.0 77 64 141
11.0
<1>
64 58 122
2A0018 17.5 101 67 168
14.0
<1>
77 60 137
2A0021 21 138 83 222
17.5
<1>
101 67 168
2A0030 30 262 117 379
25
<1>
194 92 287
2A0040 40 293 145 437
33
<1>
214 105 319
2A0056 56 371 175 546
47
<1>
280 130 410
2A0069 69 491 205 696
60
<1>
395 163 558
2A0081 81 527 257 785
75
<1>
460 221 681
2A0110 110 719 286 1005
85
<1>
510 211 721
2A0138 138 842 312 1154
115
<1>
662 250 912
2A0169 169 1014 380 1394
145
<1>
816 306 1122
2A0211 211 1218 473 1691
180
<2>
976 378 1354
2A0250 250 1764 594 2358
215
<2>
1514 466 1980
2A0312 312 2020 665 2686
283
<2>
1936 588 2524
2A0360 360 2698 894 3591
346
<2>
2564 783 3347
2A0415 415 2672 954 3626
415
<3>
2672 954 3626
<1> Value assumes the carrier frequency is set to 8 kHz or less.
<2>
Value assumes the carrier frequency is set to 5 kHz or less.
<3> Value assumes the carrier frequency is set to 2 kHz.
Table A.12 Watt Loss 400 V Class Three-Phase Models
Drive Model
Normal Duty Heavy Duty
Rated Amps
(A)
<3>
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
Rated Amps
(A)
Heatsink Loss
(W)
Interior Unit
Loss (W)
Total Loss (W)
4A0002 2.1 20 48 68
1.8
<1>
15.9 45 61
4A0004 4.1 32 49 81
3.4
<1>
25 46 70
4A0005 5.4 45 53 97
4.8
<1>
37 49 87
4A0007 6.9 62 59 121
5.5
<1>
48 53 101
4A0009 8.8 66 60 126
7.2
<1>
53 55 108
4A0011 11.1 89 73 162
9.2
<1>
69 61 130
4A0018 17.5 177 108 285
14.8
<1>
135 86 221
4A0023 23 216 138 354
18.0
<1>
150 97 247
4A0031 31 295 161 455
24
<1>
208 115 323
4A0038 38 340 182 521
31
<1>
263 141 403
4A0044 44 390 209 599
39
<1>
330 179 509
4A0058 58 471 215 686
45
<1>
349 170 518
4A0072 72 605 265 870
60
<1>
484 217 701
A.4 Drive Watt Loss Data
246
YASKAWA ELECTRIC TOEP C710616 41G YASKAWA AC Drive - A1000 Quick Start Guide

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
